多色虚拟荧光辐射差分显微成像

黄宇然 张智敏 董婉潔 徐良 韩于冰 郝翔 匡翠方 刘旭

黄宇然, 张智敏, 董婉潔, 徐良, 韩于冰, 郝翔, 匡翠方, 刘旭. 多色虚拟荧光辐射差分显微成像[J]. 中国光学(中英文). doi: 10.37188/CO.2022-0080
引用本文: 黄宇然, 张智敏, 董婉潔, 徐良, 韩于冰, 郝翔, 匡翠方, 刘旭. 多色虚拟荧光辐射差分显微成像[J]. 中国光学(中英文). doi: 10.37188/CO.2022-0080
HUANG Yu-ran, ZHANG Zhi-min, DONG Wan-jie, XU Liang, HAN Yu-bing, HAO Xiang, KUANG Cui-fang, LIU Xu. Multicolor virtual fluorescence emission difference microscopy[J]. Chinese Optics. doi: 10.37188/CO.2022-0080
Citation: HUANG Yu-ran, ZHANG Zhi-min, DONG Wan-jie, XU Liang, HAN Yu-bing, HAO Xiang, KUANG Cui-fang, LIU Xu. Multicolor virtual fluorescence emission difference microscopy[J]. Chinese Optics. doi: 10.37188/CO.2022-0080

多色虚拟荧光辐射差分显微成像

doi: 10.37188/CO.2022-0080
基金项目: 国家自然科学基金(No. 61827825、No. 62125504和No. 61735017); 浙江省自然科学基金重大项目(No. LD21F050002); 浙江省重点研究计划(No. 2020C01116); 之江实验室(No. 2020MC0AE01); 浙江省青年拔尖人才万人计划(No. 2020R52001); 中国博士后科学基金(No. BX2021272)
详细信息
    作者简介:

    黄宇然(1998—),男,陕西西安人,博士研究生,2020年于浙江大学获得学士学位,主要从事光学超分辨显微成像方面的研究。E-mail:huangyr@zju.edu.cn

    匡翠方(1977—),男,江西泰和人,博士,教授,博士生导师,主要从事光学超分辨显微成像方面的研究。E-mail:cfkuang@zju.edu.cn

  • 中图分类号: O436

Multicolor virtual fluorescence emission difference microscopy

Funds: Supported by National Natural Science Foundation of China (No. 61827825, No. 62125504 and No. 61735017); Major Program of the Natural Science Foundation of Zhejiang Province (No. LD21F050002); Key Research and Development Program of Zhejiang Province (No. 2020C01116); Zhejiang Lab (No. 2020MC0AE01); Zhejiang Provincial Ten Thousand Plan for Young Top Talents (No. 2020R52001); the China Postdoctoral Science Foundation (No. BX2021272).
More Information
  • 摘要: 荧光辐射差分显微成像是一种荧光染料普适性强、光毒性较低的超分辨成像技术。然而传统荧光辐射差分成像由于原理限制,其系统复杂度较高,稳定性低且成像速度受限。为了改进这些缺陷,本文设计搭建了一套多色虚拟荧光差分显微系统,并对该系统的成像方法和参数间的制约关系进行了分析,在已有的多色虚拟荧光辐射差分显微术原理的基础上,进一步考虑了信噪比和背景噪声等的影响,建立了可通过实验验证的虚拟荧光辐射差分显微成像模型。实验表明,本系统与方法具有结构简单、背景去噪能力强、荧光染料普适性强以及光毒性低等特性,成像分辨率较共聚焦提升了1.9倍,成像速度较传统的荧光辐射差分显微系统提升一倍,在三个波长上均获得了良好的成像效果,并在生物细胞成像中得到实验验证。



  • 图 1  虚拟荧光辐射差分显微系统简图

    Figure 1.  Sketch of virtual fluorescence emission difference microscopy

    图 2  系统成像模型,(a)中心通道、最左侧与最右侧通道的PSF的归一化强度分布;(b)光子重组后外轮廓匹配的PSF;(c)空心光斑图像仅来自中心通道时的虚拟实心PSF、空心PSF和vFED图像的PSF;(d)倾向于保证信噪比时的各图像PSF;(e)考虑背景噪声时的各图像PSF;(f)vFED与共聚焦以及实心光斑光子重组方法的成像性能对比

    Figure 2.  Imaging model of the system, (a) normalized intensity of PSFs in the center, leftmost and rightmost channels; (b) PSFs with matching outer contours after photon reassignment; (c) hollow PSF, and vFED PSF when hollow spot images from only the center channel virtual solid PSF; (d) PSF of each image when the signal-to-noise ratio tends to be guaranteed; (e) PSF of each image when the background noise is considered; (f) vFED, confocal, solid spot photon reassignment performance comparison

    图 3  荧光颗粒成像结果,(a)共聚焦图像;(b)实心光斑光子重组图像;(c)vFED图像,图(a−c)中方框内的区域高斯拟合得到的半高全宽分别为425.75 nm、320.96 nm、224.72 nm;(d)虚拟实心光斑图像;(e)空心光斑图像;(f)图(a−c) 中白色截线的归一化强度分布

    Figure 3.  Fluorescent particle imaging results, (a) confocal image; (b) solid spot photon reassignment image; (c) vFED image, the full width at half of the maximum obtained by Gaussian fitting of the regions in the box in (a−c). The widths are 425.75 nm, 320.96 nm and 224.72 nm, respectively,; (d) virtual solid spot image; (e) hollow spot image; (f) normalized intensity of the white truncation line in Figures (a−c)

    图 4  三色生物样品成像结果,(a)实心光斑光子重组图像;(b)(a)中方框内的区域的放大图;(c)同一区域的 vFED 图像

    Figure 4.  Imaging results of three-color biological samples, (a) solid spot photon reassignment image; (b) enlarged view of the area inside the box in (a); (c) vFED image of the same area

  • [1] ABBE E. Beiträge zur theorie des mikroskops und der mikroskopischen wahrnehmung[J]. Archiv für Mikroskopische Anatomie, 1873, 9(1): 413-468.
    [2] HELL S W, WICHMANN J. Breaking the diffraction resolution limit by stimulated emission: stimulated-emission-depletion fluorescence microscopy[J]. Optics Letters, 1994, 19(11): 780-782. doi: 10.1364/OL.19.000780
    [3] KUANG C F, LI SH, LIU W, et al. Breaking the diffraction barrier using fluorescence emission difference microscopy[J]. Scientific Reports, 2013, 3: 1441. doi: 10.1038/srep01441
    [4] BETZIG E, PATTERSON G H, SOUGRAT R, et al. Imaging intracellular fluorescent proteins at nanometer resolution[J]. Science, 2006, 313(5793): 1642-1645. doi: 10.1126/science.1127344
    [5] RUST M J, BATES M, ZHUANG X W. Sub-diffraction-limit imaging by stochastic optical reconstruction microscopy (STORM)[J]. Nature Methods, 2006, 3(10): 793-796. doi: 10.1038/nmeth929
    [6] GUSTAFSSON M G L. Surpassing the lateral resolution limit by a factor of two using structured illumination microscopy[J]. Journal of Microscopy, 2000, 198(2): 82-87. doi: 10.1046/j.1365-2818.2000.00710.x
    [7] MA Y, KUANG C F, FANG Y, et al. Virtual fluorescence emission difference microscopy based on photon reassignment[J]. Optics Letters, 2015, 40(20): 4627-4630. doi: 10.1364/OL.40.004627
    [8] HE M F, HAN Y B, GAN Y H, et al. Dynamic live-cell super-resolution imaging with parallelized fluorescence emission difference microscopy[J]. Optics Communications, 2020, 460: 125087. doi: 10.1016/j.optcom.2019.125087
    [9] 张智敏, 黄宇然, 刘少聪, 等. 共路并行荧光辐射差分超分辨显微成像[J]. 中国激光,2021,48(16):1607002. doi: 10.3788/CJL202148.1607002

    ZHANG ZH M, HUANG Y R, LIU SH C, et al. Common-path parallel fluorescence emission difference super-resolution microscopy[J]. Chinese Journal of Lasers, 2021, 48(16): 1607002. (in Chinese) doi: 10.3788/CJL202148.1607002
    [10] LIU SH C, SUN SH Y, KUANG C F, et al. Saturated virtual fluorescence emission difference microscopy based on detector array[J]. Optics Communications, 2017, 395: 45-50. doi: 10.1016/j.optcom.2016.05.024
    [11] MÜLLER C B, ENDERLEIN J. Image scanning microscopy[J]. Physical Review Letters, 2010, 104(19): 198101. doi: 10.1103/PhysRevLett.104.198101
    [12] SHEPPARD C J R, MEHTA S B, HEINTZMANN R. Superresolution by image scanning microscopy using pixel reassignment[J]. Optics Letters, 2013, 38(15): 2889-2892. doi: 10.1364/OL.38.002889
    [13] RICHARDS B, WOLF E. Electromagnetic diffraction in optical systems, II. Structure of the image field in an aplanatic system[J]. Proceedings of the Royal Society A:Mathematical,Physical and Engineering Sciences, 1959, 253(1274): 358-379.
    [14] LIU X, PENG Y F, TU SH J, et al. Generation of arbitrary longitudinal polarization vortices by pupil function manipulation[J]. Advanced Photonics Research, 2021, 2(1): 2000087. doi: 10.1002/adpr.202000087
    [15] WANG N, KOBAYASHI T. Numerical study of the subtraction threshold for fluorescence difference microscopy[J]. Optics Express, 2014, 22(23): 28819-28830. doi: 10.1364/OE.22.028819
