切向气流对激光加热金属板非熔化穿孔效应的影响

刘峰; 彭国良; 杜太焦; 郑艳丽; 阎辉

doi:10.3788/CO.20130603.0332

切向气流对激光加热金属板非熔化穿孔效应的影响

doi: 10.3788/CO.20130603.0332

刘峰^1,2, ,,
彭国良¹,
杜太焦^1,2,
郑艳丽¹,
阎辉¹

1.
西北核技术研究所第五研究室, 陕西西安710024;
2.
激光与物质相互作用国家重点实验室, 陕西西安710024

基金项目:

激光与物质相互作用国家重点实验室基金资助项目(No.SKLLIM1102)

详细信息

作者简介:
刘峰(1962-),男,陕西榆林人,博士,研究员,1983年于兰州大学获得学士学位,1991年于西北核技术研究所获得硕士学位,2006年于西安电子科技大学获得博士学位,主要从事强激光大气传输及目标效应的理论和数值模拟研究。E-mail:liufeng-laser@163.com;彭国良(1985-),男,湖北大冶人,硕士,助理研究员,2006于清华大学获得学士学位,2009年于西北核技术研究所获得硕士学位,主要从事强激光效应的理论和数值模拟方面的研究。E-mail:pgl02@163.com

刘峰(1962-),男,陕西榆林人,博士,研究员,1983年于兰州大学获得学士学位,1991年于西北核技术研究所获得硕士学位,2006年于西安电子科技大学获得博士学位,主要从事强激光大气传输及目标效应的理论和数值模拟研究。E-mail:liufeng-laser@163.com;彭国良(1985-),男,湖北大冶人,硕士,助理研究员,2006于清华大学获得学士学位,2009年于西北核技术研究所获得硕士学位,主要从事强激光效应的理论和数值模拟方面的研究。E-mail:pgl02@163.com

通讯作者:
刘峰

中图分类号: TN249;TG665
计量
- 文章访问数: 3150
- HTML全文浏览量: 664
- PDF下载量: 586
- 被引次数: 0
出版历程
- 收稿日期: 2013-02-16
- 修回日期: 2013-04-17
- 刊出日期: 2013-06-10

Influence of tangential airflows on burn-through effect with no-melting of metal heated by laser

1.
The 5th Research Laboratory, Northwest Institute of Nuclear Technology, Xi'an 710024, China;
2.
State Key Laboratory of Laser Interaction with Matter, Xi'an 710024, China

摘要

摘要: 针对切向气流加载导致激光加热金属板在熔化前的穿孔效应,利用金属薄板的弹性弯曲理论,推导出了两种典型光束(方形和圆形)照射下的弯曲挠度表达式,利用Mises理论给出了非熔化穿孔的破坏判据。研究结果表明:激光加热下材料强度降低是出现非熔化穿孔破坏的主要机理;薄板在光斑区的最大变形与气流速度、光斑直径、板厚与弹性模量(U2a4/Eh3)相关,穿孔破坏温度与气流速度、光斑直径及板厚(Ua/h)2相关;与方形光斑辐照相比,圆形光斑辐照的破坏阈值稍高一些。数值计算结果表明:0.8 Ma切向气流作用下,铝合金壳体的激光破坏能量阈值大大降低(可达40%~50%),典型不锈钢壳体的破坏阈值降低相对较小(20%左右),气流作用导致金属板破坏阈值的下降是需特别关注的问题。
- 激光辐照 /
- 激光加热 /
- 切向气流 /
- 薄板弹性弯曲 /
- 非熔化穿孔效应 /
- 破坏温度
Abstract: On the basis of elastic bending theory, the bending deflection expression by both quadrate and circinal facula irradiations is deduced for burn-through effect with no-melting of metal heated by a laser caused by tangential airflows. A rupture criterion for burn-through with no-melting is given out by the Mises theory. The study indicates that the material softened by laser heating is the primary mechanism for burn-through effect with no-melting. The maximal deflection of thin plate in the spot area is related to the airflow speed, spot diameter, plate thickness and the elasticity modulus(expression is U2a4/Eh3), the damage temperature is related to the airflow speed, spot diameter and the plate thickness(expression is (Ua/h)2), and the damage threshold under the circinal facula irradiated is higher than that under the quadrate facula. The numerical result indicates that for aluminum alloy shell, the damage threshold of laser energy can decrease much up to 40%-50% under 0.8 Ma tangential airflows, but it can decrease less(about 20%) for a stainless steel shell. The damage threshold decrease under airflows needs more attention.
- laser irradiation /
- laser heating /
- tangential airflow /
- thin plate elastic bending /
- burn-through with no-melting effect /
- damage temperature

HTML全文

参考文献(1)

[1] BOLEY C D,RUBENCHIK A M. Modeling of high-energy pulsed laser interactions with coupons,UCRL-ID-151857. U.S.Department of Energy,2003. [2] ABBOTT R P,BOLEY C D,FOCHS S N,et al.. High-power solid-state laser lethality testing and modeling,FL,UCRL-JRNL-234510. 25th Annual Army Science Conference Orlando,2006. [3] BOLEY C D,FOCHS S N,RUBENCHIK A M. Lethality of a high-power solid-state laser,NM,UCRL-JRNL-234510. Ninth Annual Directed Energy Symposium, Albuquerque,2006. [4] BOLEY C D,RUBENCHIK A M. Modeling of laser-induced metal combustion,CA,LLNL-CONF-401854. 5th Annual High Energy Laser Lethality Conference Monterey,2008. [5] BOLEY C D,FOCHS S N,RUBENCHIK A M. Large-spot material interactions with a high-power solid-state laser beam,UCRL-JRNL-406423 [R]. Journal of Directed Energy,2008. [6] BOLEY C D,CUTTER K P,FOCHS S N,et al,Study of laser interaction with thin targets,CA,LLNL-PROC-411215 [R]. Sixth Annual High Energy Laser Lethality Conference Monterey,2009. [7] 刘峰,吴振森,王玉恒. 重复频率激光辐照柱壳的加热效率[J]. 中国激光,2006,33(4):461-466 LIU F,WU ZH S,WANG Y H. The heating efficiency of a RF intensity laser-irradiated Cylinder[J]. Chinese J. Lasers,2006,33(4):461-466.(in Chinese) [8] 吴克跃;宋军;吴兴举. 激光辐照和高温氧化硅锗合金的低维结构和发光特性[J]. 发光学报,2009,30(4):541-544. WU K Y,SONG J,WU X J. The low-dimensional structure and luminescence of nano sige alloy formed by laser irradiation and high temperature oxidation[J]. Chinese J. Luminescence,2009,30(4):541-544.(in Chinese) [9] 金方圆,鄂书林,王海峰,等. 短脉冲激光加工双温方程的优化运算[J]. 发光学报,2012,(10):1143-1148. JIN F Y,E SH L,WANG H F,et al., Calculation of an optimized two temperature model for ultra-short laser ablation[J]. Chinese J. Luminescence,2012,(10):1143-1148.(in Chinese) [10] 刘剑,陆建,倪晓武,等. 单晶硅片在脉冲激光作用下的断裂行为[J]. 光学精密工程,2011,19(2):414-420. LIU J,LU J,NI X W,et al.. Fracture behavior during pulsed laser irradiating silicon wafer[J]. Opt. Precision Eng.,2011,19(2):414-420.(in Chinese) [11] 刘峰,陈雨生,吴振森. 基于充压柱壳损伤形态的靶面激光参数估计[J]. 中国激光,2007,34(6):797-803. LIU F,CHEN Y SH,WU ZH S. Estimation of laser beam-parameters based on damage configuration of a cylindrical shell subjected to internal pressure[J]. Chinese J. Lasers,2007,34 (6):797-803.(in Chinese) [12] 陈敏孙, 江厚满. 切向空气气流对激光烧蚀碳纤维复合材料过程的影响[J]. 光学精密工程,2011,19(2):482-486. CHEN M S,JIANG H M. Influence of tangential airflows on process of laser ablating carbon-fiber composites[J]. Opt. Precision Eng.,2011,19(2):482-486.(in Chinese) [13] 徐秉业,刘信声.应用弹塑性力学[M]. 北京:清华大学出版社,1995. XU B Y,LIU X SH. Applied Elastic-plastic Mechanics[M]. Beijing:Tsinghua University Press,1995.(in Chinese) [14] 吴连元编著.板壳理论[M]. 上海:上海交通大学出版社,1989. WU L Y. Theory of Plates and Shells[M]. Shanghai:Shanghai Jiaotong University Press,1989.(in Chinese) [15] TIMOSHENKO S,WOINOWSKY-KRIEGER S. Theory of Plates and Shells[M]. 2nd ed. New York:McGraw-Hill Book Company,Inc.,1959. [16] Departments and Agencies of the Department of Defense and the Federal Aviation Administration Metallic Materials and Elements for Aerospace Vehicle Structures,MIL-HDBK-5J [EB/OL].(1998-12-01) [2013-02-11].http://www.doc88.com/p-982701688821.html.2003. [17] 黄伯云,李成功,石力开,等.中国材料工程大典:有色金属材料工程[M]. 北京:化学工业出版社,2006. HUANG B Y,LI CH G,SH L K,et al.. China Materials Engineering Canon:Non-ferrous Metal Materials Engineering[M]. Beijing:China Chemistry Industry Press,2006.(in Chinese) [18] 干勇,田志凌,董瀚,等.中国材料工程大典:钢铁材料工程[M]. 北京:化学工业出版社,2006. GAN Y,TIAN ZH L,DONG H. China Materials Engineering Canon:Iron and Steel Materials Engineering[M]. Beijing:China Chemistry Industry Press,2006.(in Chinese)
