Design of infrared optical system with super-long focal length and dual field-of-view
-
摘要: 设计了一种超长焦距中波红外双视场光学系统,该系统采用二次成像结构,通过透镜轴向移动实现变焦功能。设计结果表明,该系统可以实现超长焦距600~150 mm的变焦功能,且中心视场在探测器特征频率20 lp/mm处的光学传递函数值高于0.5,接近衍射极限,能够很好地满足军事侦察对远距离目标同时搜索和瞄准的要求。Abstract: A mid-wavelength infrared optical system with super-long focal length and dual field-of-view is designed in this paper. Based on the re-image configuration, this system can realize the zoom by axial motion of a lens along the optical axis. The design results show that this system realizes the zoom with a super-long focal length of 600-1 500 mm, and the MTF of the central view is more than 0.5 at the characteristic frequency of 20 lp/mm of detector, which shows its optical performance approximates to the diffraction limit. This system can meet the requirement of military investigation for seeking and aiming at target in a long distance.
-
[1] 胡际先. 长焦距大口径连续变焦光学系统的设计[J]. 应用光学,2007,28(5):569-573. HU J X. Design of long focal length large aperture optical zoom system[J]. J. Appl. Optics,2007,28(5):569-573.(in Chinese)
[2] 杨智,戴一帆,张沛. 折衍混合在长焦物镜中的应用研究[J]. 激光技术,2007,31(2):206-208. YANG ZH,DAI Y F,ZHANG P. The study of hybrid refractive-diffractive telephoto lens[J]. Laser Technology,2007,31(2):206-208.(in Chinese)
[3] ARTHUR COX,JONATHAN S KANE. Optically compensated zoom lens design in the infrared[J]. SPIE,2005,5783:887-898.
[4] 孟剑奇. 双视场6倍变焦红外热成像光学系统[J]. 红外与激光工程,2008,30(4):89-92. MENG J Q. Dual field zoom(6×) infrared imaging optical system[J]. Infrared and Laser Engineering,2008,30(4):89-92.(in Chinese)
[5] 陶亮,赵劲松. 5×光学补偿长波红外连续变焦物镜系统[J]. 红外技术,2008,30(4):210-213. TAO L,ZHAO J S. Optically compensated LWIR zoom objective with magnification of 5×[J]. Infrared Technology,2008,30(4):210-213.(in Chinese)
[6] SCHREER O,LÓPEZSÁENZ M,PEPPERMVLLER CH,et al.. Helicopter-borne dual-band dual-fpa system[J]. SPIE,2003,5074:637-647.
[7] ANTONIN M,JIRI N,PAVEL N. Zoom lens design[J]. SPIE,2005,8233:1-9.
[8] 魏群,艾兴乔,贾宏光. 小型可见光双视场光学系统的研制[J]. 光学精密工程,2012,20(4):739-744. WEI Q,AI X Q,JIA H G. Development of small-scale and dual-field visible light optical system[J]. Opt. Precision Eng.,2012,20(4):739-744.(in Chinese)
[9] 李晓彤,岑兆丰.几何光学·像差·光学设计[M]. 浙江:浙江大学出版社,2003. LI X T,CEN ZH F. Geometrical Optics Aberrations and Optical Design[M]. Zhejiang:Zhejiang University Press,2003.(in Chinese)
[10] 张以谟.应用光学[M]. 北京: 机械工业出版社,1982. ZHANG Y M. Applied Optics[M]. Beijing:China Machine Press,1982.(in Chinese)
