Mechanism of the enhanced fluorescence of SiO2-coated ZnS nanoparticles
-
摘要: 为了明确团聚现象及表面性质对ZnS纳米材料发光性质的影响,采用SiO2对ZnS材料进行了表面修饰,并对ZnS及ZnS/SiO2复合材料的光学性质进行对比研究.采用吸收光谱分析了包覆前后光吸收性质的差异,发现SiO2包覆后ZnS纳米材料的带边由333 nm红移至360 nm.为了研究ZnS纳米材料与ZnS/SiO2纳米复合材料的光发射性质,分别对含纳米材料的水溶液样品及粉末样品的发光光谱进行了采集.对比研究的结果表明,SiO2包覆后ZnS纳米材料在蓝紫光区的发光得到了明显增强.以氙灯作为激发光源所获得荧光光谱显示ZnS/SiO2粉末样品发光的积分强度增大为原来的17.5倍,但相同条件下针对溶液样品的测试结果显示其发光强度只增大了1.1倍,这种增强可用SiO2的存在抑制了ZnS纳米粒子间的团聚来解释,且这一推断由325 nm紫外激光激发下获得的光致发光数据进行了验证.Abstract: In order to investigate the influence of aggregation and surface effect on the optical properties of ZnS nanoparticles, SiO2 is used to modify the surface of ZnS nanoparticles. The optical properties of the synthesized ZnS and ZnS/SiO2 nanoparticles are both studied for making a comparison. According to the absorption spectra recorded by an ultraviolet-visible spectrophotometer, the band gap edge red-shifts from 333 nm to 360 nm. To analyze the emission properties, the fluorescence spectra of the solution and the powders containing the ZnS or ZnS/SiO2 nanoparticles are both collected. It is found that the light emission of the ZnS nanoparticles in the violet to blue region is enhanced obviously when SiO2 is introduced. When the samples are excitated by a xenon lamp, the integrated fluorescence intensity of the ZnS/SiO2 nanoparticles is enhanced by 17.5 times. However, a much smaller enhancement is found in the measurement for the solution samples. The fluorescence is only 1.1 times higher after coating ZnS nanoparticles by SiO2. The inhibition of the aggregation between the ZnS nanoparticles by the SiO2 coated layer is supposed to be responsible for the enhancement, which is confirmed by the photoluminescence data where a 325 nm He-Cd laser is used as the excitation source.
-
Key words:
- composites /
- ZnS/SiO2 /
- luminescence /
- fluorescence enhancement
-
[1] MAO B D,CHUANG CH H,MCCLEESE C,et al.. Near-infrared emitting AgInS2/ZnS nanocrystals[J]. J. Phys. Chem. C,2014,118(25):13883-13889.
[2] SAHA S,SARKAR S,PAL S,et al.. Tuning the energy levels of ZnO/ZnS core/shell nanowires to design an efficient nanowire-based dye-sensitized solar cell[J]. J. Phys. Chem. C,2013,117(31):15890-15900.
[3] 陈赟,李艳茹,张红胜. 基于ZnS金属网栅制作工艺的改进[J]. 中国光学,2014,7(1):131-136. CHEN Y,LI Y R,ZHANG H SH. Improvement on fabrication technology of metallic mesh based on ZnS[J]. Chinese Optics,2014,7(1):131-136.(in Chinese)
[4] 田昕,曹立新,柳伟,等. 核壳型ZnS:Cu/ZnS量子点的制备及发光性质[J]. 发光学报,2012,33(7):736-741. TIAN X,CAO L X,LIU W,et al.. Synthesis and photoluminescent properties of core/shell structure ZnS:Cu/ZnS quantum dots[J]. Chin. J. Lumin.,2012,33(7):736-741.(in Chinese)
[5] 杜鸿延,魏志鹏,孙丽娟,等. 与掺杂浓度相关的ZnS:Mn纳米粒子的发光性质[J]. 中国光学,2013,6(1):111-116. DU H Y,WEI ZH P,SUN L J,et al.. Luminescent properties of ZnS:Mn nanoparticles dependent on doping concentration[J]. Chinese Optics,2013,6(1):111-116.(in Chinese)
[6] SUN X L,HUANG X L,GUO J X,et al.. Self-illuminating 64Cu-doped CdSe/ZnS nanocrystals for in vivo tumor imaging[J]. J. Am. Chem. Soc.,2014,136(5):1706-1709.
[7] CHEN W,SU F H,LI G H,et al. Temperature and pressure dependence of the Mn2+ and donor-acceptor emissions in ZnS:Mn2+ nanoparticles[J]. J. Appl. Phys.,2002,92:1950.
[8] INSIN N,TRACY J B,LEE H,et al. Incorporation of iron oxide nanoparticles and quantum dots into silica microspheres[J]. ACS Nano,2008,2(2):197-202.
[9] 王英帅,周颖,王珺楠,等. 金纳米棒核/二氧化硅壳纳米复合结构的可控制备及细胞成像[J]. 中国光学,2013,6(5):743-749. WANG Y SH,ZHOU Y,WANG J N,et al.. Controlled synthesis and cell imaging of gold nanorod-silica core-shell nanoparticles[J]. Chinese Optics,2013,6(5):743-749.(in Chinese)
[10] TANG D P,YUAN R,CHAI Y Q,et al.. Magnetic-core/porous-shell CoFe2O4/SiO2 composite nanoparticles as immobilized affinity supports for clinical immunoassays[J]. Adv. Funct. Mater,2007,17:976-982.
[11] LI ZH Q,ZHANG Y. Monodisperse silica-coated polyvinyl-pyrrolidone/NaYF4 nanocrystals with multicolor upconversion fluorescence emission[J]. Angew. Chem. Int. Ed.,2006,45:7732-7735.
[12] FODA M F,HUANG L,SHAO F,et al.. Biocompatible and highly luminescent near-infrared CuInS2/ZnS quantum dots embedded silica beads for cancer cell imaging[J]. ACS Appl. Mater. Interfaces,2014,6(3):2011-2017.
[13] JIN C,LEE J,BAEK K,et al. Preparation, structure and photoluminescence properties of SiO2 coated ZnS nanowires[J]. Cryst. Res. Technol.,2010,45(10):1069 1074.
[14] 秦俊杰,曹立新,柳伟,等. ZnS:Mn/SiO2量子点的表面聚乙烯吡咯烷酮修饰及其应用于海水中铅离子检测[J]. 发光学报,2014,35(7):858-865. QIN J J,CAO L X,LIU W,et al.. ZnS:Mn/SiO2 quantum dots modified with PVP as fluorescent sensor for Pb2+ ions in sea water[J]. Chin. J. Lumin.,2014,35(7):858-865.(in Chinese)
[15] MA L,CHEN W. Luminescence enhancement and quenching in ZnS:Mn by Au Nanoparticles[J]. J. Appl. Phys.,2010,107:123513. -
