基于同心球透镜的四镜头探测器阵列拼接成像系统

徐明飞; 黄玮

doi:10.3788/CO.20140706.0936

基于同心球透镜的四镜头探测器阵列拼接成像系统

doi: 10.3788/CO.20140706.0936

徐明飞^1,2,
黄玮¹

1.
中国科学院长春光学精密机械与物理研究所应用光学国家重点实验室, 吉林长春 130033;
2.
中国科学院大学, 北京 100049

详细信息

作者简介:
徐明飞(1987- ), 男, 吉林磐石人, 博士研究生, 2010年于天津大学获得学士学位, 主要从事光学设计方面的研究.E-mail:stone870914@163.com

中图分类号: V245.6;O439
计量
- 文章访问数: 1753
- HTML全文浏览量: 287
- PDF下载量: 587
- 被引次数: 0
出版历程
- 收稿日期: 2014-09-21
- 修回日期: 2014-11-23
- 刊出日期: 2014-11-25

Detectors arrays mosaic imaging system based on four sets of monocentirc lens

XU Ming-fei^1,2,
HUANG Wei¹

1.
State Key Laboratory of Applied Optics, Changchun Institute of Optics, Fine Mechanics and Physics, Chinese Academy of Sciences, Changchun 130033, China;
2.
University of Chinese Academy of Sciences, Beijing 100049, China

摘要

摘要: 为了同时实现成像系统的大视场、长焦距和高分辨率,设计了基于同心球透镜的四镜头探测器阵列拼接成像系统.首先,阐述了四镜头探测器阵列拼接方案的原理;介绍了同心球透镜的结构特点,阐述了其成像优点.然后,完成了满足实际拼接应用的同心球广角、长焦成像系统(拼接子系统)的光学设计.最后,给出了拼接子系统的像质评价并对其进行公差分析.结果表明:拼接后的系统可实现100 mm焦距和120视场成像.该系统解决了大视场和长焦距之间的矛盾,可实现超高像素成像,相对于传统光电成像系统具有巨大的优势.
- 同心球透镜 /
- 探测器阵列 /
- 超高像素成像
Abstract: In order to achieve both wide field of angle and high resolution in one imaging device, we propose a method which combines detectors arrays mosaic technique and monocentric imaging lens. This paper first introduces the scheme of detectors mosaic of four lens systems, and next there is a thorough discussion of advantages by adopting monocentric objective lens. After that, a completed lens design prescription is presented as well as the related specifications. In the final part, evaluation of the imaging quality is discussed along with the tolerance sensitivity analysis. The finished system has 120 FOV and 100 mm focal length. As depicted, the contradiction between wide field of angle and long-focus has been figured out excellently by the monocentric mosaic imaging system which can complete ultra-high resolution imaging and has great advantage compared with other imaging devices.
- monocentirc lens /
- sensors arrays /
- ultra-high resolution imaging

HTML全文

参考文献(1)

[1] 陈琛,胡春海. 球幕投影通用型变焦鱼眼镜头设计[J]. 光学精密工程,2013,21(2):323-335. CHEN CH,HU CH H. Design of general type zoom fish-eye lens for dome-screen projector[J]. Opt. Precision Eng.,2013,21(2):323-335.(in Chinese)
[2] 郭疆,孙继明,邵明东,等. 离轴三反航天测绘相机焦距的计算[J]. 光学精密工程,2012,20(8):1754-1758. GUO J,SUN J M,SHAO M D,et al.. Calculation of focal length for off-axis TMA aerospace mapping camera[J]. Opt. Precision Eng.,2012,20(8):1754-1758.(in Chinese)
[3] 龚大鹏,郭疆,王国良,等. 长焦距离轴三反测绘相机的外场立体成像[J]. 光学精密工程,2013,21(1):137-143. GONG D P,GUO J,WANG G L,et al.. Outdoor stereoscopic imaging of mapping camera with long focus off-axis three-mirror[J]. Opt. Precision Eng.,2013,21(1):137-143.(in Chinese)
[4] DANIEL L M,ERIC J T,JOSEPH E F,et al.. Microcamera aperture scale in monocentric gigapixel camera[J]. Applied Optics,2011,50(30):5824-5833.
[5] MARKS D L,SON H S,KIM J,et al.. Engineering a gigapixel monocentric multiscale camera[J]. Optical Engineering,2012,51(8):1-11.
[6] TREMBLAY E J,MARKS D L,BRADY D J,et al.. Design and scaling of monocentric multiscale imagers[J]. Applied Optics,2012,51(20):4691-4702.
[7] 史光辉,杨威. 用于图像拼接的电视摄像光学系统[J]. 中国光学,2014:2095-1531. SHI G H,YANG W. Optical system used to compose images in television photograph[J]. Chinese Optics,2014:2095-1531.(in Chinese)
[8] BRIAN L,JONATHAN E,JOHN A,et al.. Autonomous real-time ground ubiquitous surveillance-imaging system(ARGUS-IS)[J]. SPIE,2008,6981:69810H-1.
[9] 冯华军,刘旭,刘承,等. 实现多CCD无缝拼接的光电系统:中国,200710069052.4[P],2007. FENG H J,LIU X,LIU CH. A photoelectric system achieved by the stitch of multi-CCDs:China,200710069052.4,2007.(in Chinese)
[10] 李晓彤,岑兆丰. 几何光学·像差·光学设计[D].杭州:浙江大学出版社,2003. LI X T,CEN ZH F. Geometrical Optics, Aberrations and Optical Design[D]. Hangzhou: Zhejiang University Press,2003.(in Chinese)
