大视场曲面复眼光学系统设计

王晶; 崔恩坤

doi:10.3788/CO.20140706.0969

大视场曲面复眼光学系统设计

doi: 10.3788/CO.20140706.0969

王晶¹,
崔恩坤^1,2

1.
中国科学院长春光学精密机械与物理研究所, 吉林长春 130033;
2.
中国科学院大学, 北京 100049

基金项目:

国家高技术研究发展计划(863计划)资助项目(No.2013AA122102)

详细信息

作者简介:
崔恩坤(1988- ), 男, 山东临沂人, 硕士研究生, 2012年于兰州大学获得学士学位, 主要从事机载红外光学系统设计方面的研究.E-mail:cuiek08@163.com

中图分类号: TH703
计量
- 文章访问数: 1865
- HTML全文浏览量: 283
- PDF下载量: 683
- 被引次数: 0
出版历程
- 收稿日期: 2014-09-15
- 修回日期: 2014-11-12
- 刊出日期: 2014-11-25

Design of large FOV curved artificial compound eye with freeform lens

WANG Jing¹,
CUI En-kun^1,2

1.
Key Laboratory of Airborne Optical Imaging and Measurement, Changchun Institute of Optical, Fine Mechanics and Physics, Changchun 130033, China;
2.
University of Chinese Academy of Sciences, Beijing 100049, China

摘要

摘要: 本文通过结构性设计解决了曲面复眼光学系统边缘视场像质难以提高的问题.该光学系统由7个相互独立的子复眼光学系统组成,各子复眼光学系统相互独立,其光线相互交叉.在系统中引入自由曲面透镜,自由曲面透镜相当于棱镜将微透镜阵列光线偏折,使同一子系统的微透镜成像于平的像面上.每个子系统包括一层微透镜阵列,一个自由曲面透镜,一光阑阵列和后续像差校正镜.相比较于传统的复眼系统,该结构对复眼边缘视场的像差校正能力更强,能很大程度地提高边缘视场的像质.该系统的理论视场可达180,制造精密要求不高且适用性强.本文最后通过光学软件zemax对光学系统进行了模拟验证,证明其可实现性.
- 光学设计 /
- 曲面 /
- 复眼 /
- 自由曲面
Abstract: This research demonstrated an innovative and integrated approach to design 3D compound eye optical structure which composed of seven sub-systems, and to improve image quality of marginal FOV. For every sub-system, it is an unattached optical system with cross light path, which consists of a mircolens array layer, an aperture stop array, and integrating freeform lens which are used to make images of different mircolens onto a plane image sensor. It's easier for this structure to get better image quality for marginal FOV by reducing the maximum light deviation angle. The theoretic FOV can be as large as 180. In the meantime the requirment for fabricating accuracy is not very high. The feasibility of the proposed structure is validated with optical software.
- optical design /
- curved surface /
- compound eyes /
- freeform lens

HTML全文

参考文献(1)

[1] JEONG K H,KIM J,LEE L P. Biologically inspired artificial compound eyes[J].Science,2006,312:557-561.
[2] 张红鑫,卢振武,王瑞庭,等. 曲面仿生复眼成像系统的研究[J]. 光学精密工程,2006,8(6):23-27. ZHANG H X,LU ZH W,WANG R T,et al.. Design of compound optical system[J]. Opt. Precision Eng.,2006,8(6):23-27.(in Chinese)
[3] 巩宪伟,鱼卫星,张红鑫. 仿生复眼成像系统设计与制作的研究进展[J]. 中国光学,2012,6(1):35-40. GONG X W,YU W X,ZHANG H X. Progress in design and fabrication of artificial compound eye optical system[J]. Chinese Optics,2012,6(1):35-40.(in Chinese)
[4] DUER F,BENITEZ P,MINANO J C. Analytic design method for optical imaging:coupling three rays sets using two free-form lens profiles[J]. Opt. Express,2012,20:5576-5585.
[5] ZHU J,YANG T,JIN G F. Design method of surface contour for a freeform lens with wide linear field-of-view[J]. Opt. Express,2013,21:26080-26092.
[6] BRUNT B V. Mathematical possibility of certain systems in geometrical optics[J]. J. Opt. Soc. Am. A,1994,11:2905-2914.
[7] CHENGA D,WANGAYT,HUA H. Free form optical system design with differential equations[J]. SPIE,2010,7849:78490Q.
[8] MINANO J C,BENITEZ P,LIN W,et al. An application of the SMS method for imaging designs[J]. Opt. Express,2009,17:24036 24044.
[9] MANALA H,SU T Q,HUANG R,DOMINGUEZ M Z. Aspheric and freeform surfaces metrology with software configurable optical test system:a computerized reverse Hartmann test[J]. Opt. Eng.,2014,53:031305.
[10] CAOA A,SHI L F,SHI R Y. Image process technique used in a large FOV compound eye imaging system[J]. SPIE,2012,8558:85581K.
[11] FALLAH H R,KARIMZADEH A. MTF of compound eye[J]. Opt. Express,2010,18:12304-12310.
